LYQ-2500
LYQ-3000
Stone working machinery refers to machines and equipment used to create and shape stone for various uses. Common types of stone working machinery include diamond saws, stone bridge saws, stone milling cutters, stone engraving machines, and stone polishing machines. These machines are designed for different types of stone, such as granite, marble, sandstone, limestone, and quartz, and each type of stone requires a different type of machine.
Diamond saws are used to cut large blocks of stone into smaller pieces for further processing or to create slabs for countertops and floors. Bridge saws are able to accurately cut straight and curved lines, making them ideal for creating intricate designs. Stone milling cutters are used to shape and detail stone, while stone engraving machines are used to add personalized designs and patterns to stone. Polishing machines are used to give stone a smooth, shiny finish. Stone polishing machines are used to smooth and polish stone edges. Grinding polishing machines are used to achieve a smooth, shiny finish on flat stone surfaces or edges.
Stone working machinery requires skilled operators who understand the equipment and the characteristics of different types of stone. It is essential to select the right machinery for each specific task to ensure efficient and high-quality results. Proper care and maintenance are also essential to keep your machine in good condition and prevent breakdowns.
|
Model |
LYQ-2200 |
LYQ-2500 |
LYQ-3000 |
|
|
Max.blade diameter |
mm |
2200 |
2500 |
3000 |
|
Max.No.of blades |
pc |
3 |
1 |
1 |
|
Recommended blade combination |
mm |
2200,1600,940 |
2500 |
3000 |
|
Recommended thickness of blade |
mm |
6.5 |
6.5 |
8 |
|
Linear speed |
M/s |
37.75 |
36.75 |
36.75 |
|
Feeding speed |
Mm/min |
0-5350 |
0-5350 |
0-5350 |
|
Vertical feeding speed |
Mm/min |
590 |
590 |
590 |
|
Trolley feeding speed |
Mm/min |
200 |
200 |
200 |
|
Main motor power |
kw |
30 |
30 |
37 |
|
Table dimensions(LxH) |
mm |
2000x2000 |
2000x2000 |
2000x2000 |
|
Max.cutting size(LxWxH) |
mm |
3000x2000x950 |
3000x2000x1100 |
3400x2000x1350 |
|
Overall dimensions(LxWxH) |
mm |
6600x6000x4800 |
6600x6000x4800 |
7000x4700x6000 |
|
Water consumption |
M3/h |
6 |
6 |
10 |
|
Approximate weight |
kg |
9000 |
9000 |
12000 |
